Automatic Juice Can Filling Machine
The juice can filling machine is like the name for filling juice into metal cans;
Product Gallery
Product Video
Technical Specifications
| Model (aluminum can) | RCGF12-4 | RCGF18-6 | RCGF24-6 | RCGF30-6 | RCGF36-6 |
|---|---|---|---|---|---|
| Model (tin can) | RCGF12-12-4 | RCGF18-18-6 | RCGF24-24-6 | RCGF30-30-6 | RCGF36-36-6 |
| Production capacity CPH | 8000 | 10000 | 15000 | 18000 | 20000 |
| Main motor power (kw) | 5.5kw | 7.5kw | 10kw | 10kw | 10kw |
| Can type & lid type | No limitation, but same diameter | ||||
| Machine size (mm) | 1700*1100*2300 | 1800*1300*2300 | 1950*1600*2500 | 2100*1850*2500 | 2300*1850*2500 |
| Weight (kg) | 1200 | 1500 | 1800 | 2500 | 3200 |
| PLC | Mitsubishi / Siemens |
|---|---|
| Touch screen | Mitsubishi / Siemens |
| Contactor | Schneider |
| Rely | Schneider |
| Transducer | Shilin / Mitsubishi / Panasonic |
| Light sensor | Autonics |
| Power | Mingwei |
| Pneumatic parts | Airtac / Festo |
| Stainless steel | ZPSS |
| Motor | Domestic brand / Siemens / ABB |
| Bearing | Domestic brand / NSK |
Description
Product Description:
Automatic Juice Can Filling Machine is like the name for filling juice into metal cans; For example juice, tea drinks etc which are made of concentrate juice. The final filling temperature will be around 85-90 degree centigrade; Once the thermal meter in juice filling machine is lower than the temperature, juice will be return to sterilizing machine again through return system.
Feature::
– The machine is 3 in 1 filling machine, including bottle rinsing, juice filling and bottle capping; It is for tin can; For washing part, tin can will be sticked by magnet;
– Filling machine can be adjusted the height automatically basing on different height of bottles;
– For aluminum can, 2 in 1 filling machine will be needed, including filling and sealing; Washing tunnel will be extra machine;
– Metal cans must have the same diameter due to sealing part; It will not be shared by different diameters of cans;
– NOTE the touch screen will be apply “Pro-Face”, it can be remote control under internet condition; Once machine program down, we can modify in our factory;
– There is return system, including high position tank, return tank, vacuum pump and pump; For return juice to sterilizing machine;
– Except the juice, such filling machine can be used for filling water as well;
– The whole machine structure (all inside parts and outside structure) is totally new designed;
– Sanitary filling head system is of umbrella structure, high filling speed and perfect filling temperature control system and reflux tank system has the function of supplying the material automatically;
– More function can be added basing on requirement;
– High speed performance with less filling head;
– All the spare parts are made in one piece, which will be easy to change;
Application：
Automatic Juice Can Filling Machine is mainly designed for filling hot temperature liquid; For example juice, tea drinks etc which are made of concentrate juice.
Packaging & Delivery：
All New crown Machines will be packed with high quality plastic film, then put into the wood box increase there is crash and damages.
FAQ:
1, When you can arrange the delivery after customers place the order ?
A: Normally production time is around 30-60days,the exactly depend on what kind of machine you ordered .
2, How long time for installation?
A: According your machines order,we will arrange one or two engineers to your factory,it will take about 1 to 2 weeks.
3, What kind payment be accepted by New crown?
A: We can accept L/C,West union,TT
4, How to install my machines when it arrives?how much the cost?
A: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.Customer pay air tickets go and back,accommodation,food,and so on.USD 100/DAY/PERSON
Installation and maintenance:
The machines should have good maintenance twice for 6 months,and for installation, you can get the manual guide from Newcrown, or we can sent our engineers to help you.
